Vertikal VRT14-ES

The batteryed scissor lift platform is quiet and convenient. It can be used in closed areas such as factories, workshops, warehouses, hotels. Powered by their batteries, the scissor platform is low noise and environmentally friendly. Its compact structure allows it to pass through narrow areas and work in small areas. The scissor platform, which can be opened and closed, can be extended according to your work area via the joystick control panel. The Pop-up Tray can be rotated to facilitate maintenance, inspection and replacement.

Description

MODEL VRT14-ES

Working Height13.90
Platform Height11.90
Lifting capacity320kg
Openable Stage Lifting Capacity120kg
Length Ⓓ2.48
Width Ⓔ1.15m
Height (Closed State) Ⓒ2.59
Height (When Rails Are Storey)2.14
Min. Platform Level Ⓖ1.45m
Platform Dimensions Ⓑ * Ⓐ2.26 * 1.13M
Opening Step Length0.9m
Height-Above-Ground / Pothole Protection100 / 20mm
Turning Radius2.3m
Speed ​​(Platform Off Status)3.2km / h
Speed ​​(Platform Raised Status)0.8km / h
Climbing Ability25%
wheelsΦ381 * 127mm
Weight2580kg
Engine24 / 3v / kW
Battery4 * 6 / 251V / Oh
Charger24W / 30A
Maximum Permitted Slope1.5 ° / 3 °

olculer tablosu

HARDWARE

EngineBucher (USA)
BatteryTrojen (USA)
ChargerSignet (USA)
Hydraulic PumpParker (USA)
ValveHyroforce (USA)
Traction EngineWhite (USA)
BrakeWhite (USA)
CommandDLT (USA)
